SXGA 19" TFT-LCD Monitor 5év 30000óra gar. fekete S1901SH BK Technikai adatlap

Tech. Spec. Info : 19" / 48 cm, Flexible Edition sorozat S1901SH-BK
SXGA, 700:1 kontraszt, 300 cd/m?, 160°/160°, DVI-D és analóg, magasság állítható állvány, fekete színű

The S1901 comes with a high contrast ratio, energy-saving brightness sensor, choice of stands, and optional audio capability and is ideal for still images.

- 1280 × 1024 native resolution
- 700:1 contrast ratio
- 170° viewing angles
(at contrast ratio of 5:1)
- Digital/analog inputs

Optional Audio Capability *
The monitor can be outfitted with internal speakers if desired. The speakers are tucked away at the back of the monitor and out of view so there are no obstructions around the bezels. Monitors without speakers have the same appearance.
* Subject to local availability. For details, please contact the EIZO subsidiary or distributor in your country.

Choice of Three Stands *
Height adjustable, ArcSwing 2, and EzUp stands are available – just choose the one that suits your needs. The height
Height adjustable stand

ArcSwing stand

EzUp stand
adjustable stand provides 100 mm of vertical adjustment, 70° swivel and 30° tilt, and portrait mode display. The ArcSwing 2 stand provides 104 mm height adjustment, 60° tilt and 344° swivel. The EzUp stand is the most flexible of the three with 170 mm height adjustment, 25° tilt, 344° swivel, and portrait mode display.
* Subject to local availability. For details, please contact the EIZO subsidiary or distributor in your country.

Slim and Convenient
The bezels on this stylish monitor are extremely thin: a mere 15 mm top and bottom and 13 mm on the sides. This not only saves space on crowded desktops, it provides a near-seamless view in multi-panel configurations.

700:1 Contrast Ratio
This outstanding contrast performance makes images on dark backgrounds appear more vivid and ensures that colors retain their richness even in brightly lit rooms.

Fine Contrast
Three specialized image adjustment modes for office applications (Text mode), web applications (sRGB mode), and individual user settings (Custom mode) are available in the OSD menu.


Digital and Analog Input Terminals
DVI-D and D-Sub mini 15-pin input terminals allow the monitors to accept both digital and analog inputs. If both types are connected, you can switch between them via a front panel button.

BrightRegulator
A sensor on the front panel takes readings of the ambient brightness and signals the backlight to adjust the screen brightness accordingly. This keeps the screen at the ideal brightness level under all lightning conditions and reduces power consumption.

Product Information Display
The product name, serial number, and total usage time can all be confirmed in the on-screen display menu.

Free Mount Capability
Panel can be removed from its stand and can be mounted on VESA-compliant arms or stands.

Customer Assurance
A five-year warranty offers a long service life, and compliance with leading industry standards such as TCO’03 and TUV Ergonomics ensures a better working environment. The EIZO Eco Products 2006 label indicates these products meet strict internal requirements for design, manufacturing, packaging, and usage, including the introduction of lead-free solder and chrome-free steel plates.

odel Variations With or without built-in speakers, choice of three stands1
Panel Panel Size and Type 48 cm (19”) TFT color LCD panel
Viewing Angles (H, V) 160°, 160° (at contrast ratio of 10:1)
170°, 170° (at contrast ratio of 5:1)
Brightness / Contrast 300 cd/m2 / 700:1
On/Off Response Time
6 ms (typical)
Native Resolution 1280 × 1024
Active Display Size
(H × V) 376 × 301 mm
Viewable Image Size Diagonal: 481 mm
Pixel Pitch 0.294 × 0.294 mm
Display Colors 16.19 million (maximum)
Cabinet Colors Gray, Black
Dot Clock Analog: 135 MHz, Digital: 108 MHz
Scanning Frequency (H, V) Analog 24.8 – 80 kHz, 50 – 75 Hz
Digital 31 – 64 kHz, 59 – 61 Hz
(VGA Text: 69 – 71 Hz)
Input Signals Analog: RGB Analog, Digital: DVI Standard 1.0
Input Terminals D-Sub mini 15 pin, DVI-D 24 pin (switchable)
Plug Play VESA DDC 2B
Power Power Requirements AC 100 – 120 V, 200 – 240 V: 50 / 60 Hz
Power Consumption 45W (maximum)
Power Save Mode Less than 1 W
Physical Specifications Height Adjustment Range With Height Adjustable Stand: 100 mm
With ArcSwing: 104 mm
With EzUp Stand: 170 mm
Tilt / Swivel / Pivot With Height Adjustable Stand:
30° Up, 0° Down / 35° Right, 35° Left / 90°
With ArcSwing Stand:
60° Up, 5° Down / 172° Right, 172° Left /–
With EzUp Stand:
25° Up, 0° Down / 172° Right, 172° Left / 10° Right, 92° Left
Dimensions
(W × H × D) With Height Adjustable Stand:
405 × 406.5 – 506.5 × 205 mm
15.9 × 16.0 – 19.9 × 8.1"
With ArcSwing Stand:
405 × 288 – 423.5 × 200 mm
"15.9 × 11.3 – 16.7 × 7.9"
With EzUp Stand:
405 × 347.7 – 507 × 246.8 – 277.6 mm
15.9 × 13.4 – 20.0 × 9.7 – 10.9"
Without Stand:405 × 334 × 61.5 mm
15.9 × 13.1 × 2.42"
Net Weight With Height Adjustable Stand:
7.2 kg / 15.9 lbs
With ArcSwing Stand:
7.0 kg / 15.4 lbs
With EZ-UP Stand:
8.8 kg / 19.4 lbs
Without Stand: 5.2 kg / 11.5 lbs
Auto Brightness Functions BrightRegulator
Auto Adjustment Functions
(analog only) Auto Setup
Auto Power Save Function Analog: VESA DPMS, Digital: DVI DMPM
Display Mode Options Fine Contrast (Text, sRGB, Custom)
ScreenManager OSD Adjustment Functions Screen Adjustment
(analog only) Clock, Phase, Position, Range Adjustment (Auto)
Color Adjustment Brightness, Temperature (5,000 K, 6,500 K, 9,300 K, off), Gain, Reset
Audio
(speaker model only) Volume
Other Settings Signal Switching,Power Indicator, Product Information (product name, serial number, operating time), OSD Menu Position, BrightRegulator, Adjustment Lock, Languages (English, German, French, Italian, Japanese, Simplified Chinese, Spanish, Swedish, Traditional Chinese), Off Timer, Reset
Audio (speaker option only) Dual 0.3 W built-in speakers, input / headphone jacks
Certifications and Standards TCO'03, TÜV/Ergonomics (including ISO 13406-2), TÜV/GS, C-Tick, CE, CB, UL (cTÜVus), CSA (cTÜVus), FCC-B, Canadian ICES-003-B, TÜV/S, VCCI-B, EPA ENERGY STAR, RoHS, WEEE, CCC, EIZO Eco Products 2006
Supplied Accessories AC power cord, signal cables (D-Sub – D-Sub, DVI-D – DVI-D), audio cable (speaker model only), setup manual, CD-ROM (PDF user's manual, ICC profiles), 4 screws for mount option, warranty registration card
Warranty Five Years3
